Baoji Lihua Nonferrous Metals Co., Ltd.
7 Years
| Ask Lasest Price | |
| Brand Name : | LIHUA |
| Model Number : | LH-BL |
| Certification : | ISO9001, TUV etc. |
| Price : | US dollar $30/pc--US dollar $80/pc |
| Payment Terms : | T/T, Western Union, D/A, L/C |
| Supply Ability : | 5 tons per month |
| Delivery Time : | 3-15 work days |
ASME B16.47 Titanium Flange with Large Male-Female Connection for High Pressure Systems
Product Description:
This titanium blind flange, designed for DIN applications and rated for 1500 pressure, is extensively used in water conservancy, electric power, power stations, pipe fittings, and pressure vessels. Forged for high durability, it is ideal for both machinery and chemical applications. We also offer flanges in additional materials such as nickel and zirconium.
The Polishing Surfaced Titanium Blind Flange is a high-quality component designed for pipe connections in various applications. Crafted from premium titanium, it ensures a long service life and exceptional durability. The flange features a polished surface treatment, which enhances its corrosion resistance and overall appearance. It offers superior sealing performance and is compliant with certifications such as ISO, CE, and API. Available in various packaging options, including wooden cases and pallets, this blind flange is highly valued for its precision engineering and reliability. It is an excellent choice for diverse industrial pipe systems and applications.
Features:
Physical Properties
| Grade | Tensile strength(min) | Yeild strength(min) | Elongation (%) | ||
| ksi | MPa | ksi | MPa | ||
| GR1 | 35 | 240 | 20 | 138 | 24 |
| GR2 | 50 | 345 | 40 | 275 | 20 |
| GR5 | 130 | 895 | 120 | 828 | 10 |
| GR7 | 50 | 345 | 40 | 275 | 20 |
| GR9 | 90 | 620 | 70 | 438 | 15 |
| GR12 | 70 | 438 | 50 | 345 | 18 |
| Product name | Titanium flange |
| Type | WN |
| Standards | ASME B16.5 ASTM B381 |
| Size | 1/2" to 36" |
| Pressure Ratings | Class 150, 300#, 600#, CL 900, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 |
| Grade | gr2 gr5 gr7 gr12 |
| Other Flanges Types | Lapped Joint Flanges, Flat Flanges, Blind Flanges, Square Flanges, RTJ Flanges, Long Neck Weld Flanges, Reducing Flanges, Nipo Flanges, Threaded Flanges, Orifice Flanges, Expander Flanges, Socket Weld Flanges, High Hub Blinds Flanges, Forged Flanges, Slip On Flanges etc |
About Us:
In the last 15 years in the titanium manufacturing and exporting industry, we have excelled in crafting a wide array of titanium flanges. Our offerings include blind, neck, lap, slip-on, and plate flanges, with sizes ranging from ½" to 24". Complying with ASTM B/SB 381 standards, our products are precise and reliable. Whether you require a high volume for a major project or a single flange for a smaller task, we have the capability to deliver promptly and meet all your project needs effectively.
|
|
